Beschreibung
System CPU RK3576S Quad core cortex A53+Quad core cortex A72 RAM 4GB Internal memory 32GB Operation system Android 16 Touch screen 10-Point capacitive touch Display Panel 10.1″LCD panel Panel Type IPS Resolution 1280*800 Display Colors 16.7M Colors Viewing angle R/L 85/85, U/D 85/85 Display mode Normally black Contrast ratio 1500:1 Response Time 25ms Back-light Type ELed Luminance 280cd/m2 Aspect Ratio ,16:10 Network WiFi IEEE 802.11a/b/g/n/ac/ax Buletooth Bluetooth 5.4 Ethernet 10M/100M/1000M ethernet Interface SIM Slot 4G Flow Card SD Slot SD card ,Max support to 64GB Earphone 3.5mm earphone + Microphone USB USB 3.0 host USB USB for serial (TTL Level ) ,Optional USB Host RJ45 Ethernet interface Type-C Only supports ADB function Power jack DC power input Media play Video format MPEG-1,MPEG-2,MPEG-4,H.265,H.264,VP9,AV1, AVS2,MVC,AVC ,etc., support up to 4K Audio format MP3/WMA/AAC/WAV/OGG, etc Photo JPEG/PNG/GIF,etc Other Product Colors White/Black VESA 75*75 mm Button Power G-sensor Support 90 degrees Speaker 2*2W Microphone Single microphone NFC Optional,13.56MHz,ISO/IEC 18092, ISO/IEC 21481, ISO/IEC 14443 A&B, ISO/IEC 15693, Japanese Industrial Standard (JIS) (X) 6319-4, MIFARE Classic encrypted tags and cards RFID Optional ,125k,ISO/IEC 11784/11785,EM4100,TK4100/GK4100 LED light bar LED light bar with RGB and mixed color Camera Routine angle 5.0MP with mipi 4G Moduel Optional Language Multi-language Certificates CCC/CE/FCC POE Support IEEE802.3at,up to 30W Working Surrounding Working Temperature 0°C—40°C Storage Temperature -20°C—60°C Working Humidity 20~80%RH Storage Humidity 10~95%RH Accessories Adapter Adapter,12V/1.5A User manual *1
